Logistics Refrigerated Trucks are meticulously designed with a highly insulated body, typically constructed using polyurethane foam panels that effectively minimize heat transfer. The refrigeration unit, mounted either on top or at the front of the truck, is a powerhouse of precision cooling technology. It allows for exact temperature control, adjustable to meet the specific needs of diverse perishable goods, be it fresh produce at around 0 - 4°C, frozen items at -18°C, or pharmaceuticals within a narrow temperature range.
Inside, the cargo space is optimized with adjustable racks and shelves to secure different shapes and sizes of products. The trucks also feature robust doors with excellent seals to prevent cold air leakage.
| The specification of 8X4 30T Logistics Refrigerated Truck | ||
| Cabin | Driving type 8x4 | |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 11980*2550*3990 |
| Wheel base (mm) | 1850+4600+1350 | |
| Wheel track (front/rear) (mm) | 1460/1440 | |
| Weight in KGS | Tare Weight | 13650 |
| Payload | 17220 | |
| Front axles loading capacity | 2x5000 | |
| Rear axles loading capacity | 2x10000 | |
| Max. driving speed（km/h） | 120 | |
| Engine | Brand | Cummins |
| Model | Diesel type engine | |
| Horse Power（HP) | 340 | |
| Emission standard | Euro III | |
| Gearbox | 12 forwards & 1 reverse | |
| Fuel tank | 580L | |
| Tire | 11.00R20 tires with one spare,13 pics totally | |
| Refrigerating System | 1, Box Size: 9400*2400*2450 mm | |
| 2, Box Material, glass epoxy in the surface, foam in the middle, side, top, front, rear thickness 95mm; bottom 102 mm. | ||
| 3, Working temperature is minus 15 celsius degree. Chinese famous brand refrigeration unit | ||
| 4, Rear door open | ||
1. The chassis is the fundamental structure of logistics refrigerated trucks. It's usually a heavy-duty truck chassis made of high-strength steel. The chassis provides the necessary support for the entire vehicle and its cargo.
2. The insulated body is a key component that distinguishes refrigerated trucks from regular trucks. It's typically made of panels with a core of polyurethane foam sandwiched between two metal sheets.
3. The refrigeration unit is the heart of the logistics refrigerated truck. It's responsible for maintaining the desired temperature inside the cargo area.
4. An efficient air circulation system is essential to ensure an even temperature distribution throughout the cargo area. It consists of fans and ducts.
5. Inside the refrigerated truck, there are various cargo-handling components. There are usually adjustable shelves and racks that can be configured to fit different sizes and shapes of cargo.
6. The electrical system of a logistics refrigerated truck provides power to the refrigeration unit, lights, and other electrical components. It includes a battery, an alternator, and a wiring harness.
1. Temperature Range: Determine the specific temperature range needed for the goods you'll be transporting. Different products have different temperature needs.
2. Temperature Stability: The truck's refrigeration system should be able to maintain a consistent temperature, even during long-haul trips or in different weather conditions.
3. Cargo Volume: Consider the volume of goods you need to transport regularly. Refrigerated trucks come in various sizes, from small vans with a few cubic meters of cargo space to large semi-trailers with significant capacity.
4. Interior Layout: Examine the interior layout of the truck. It should have a practical design that allows for efficient loading and unloading.
5. Insulation Material: Check the type and quality of the insulation used in the truck's body. High-density polyurethane foam is a common and effective insulation material.
6. Sealing and Door Quality: The doors of the refrigerated truck play a crucial role in maintaining the cold environment. Ensure that the doors have strong, air-tight seals.
7. Energy Efficiency: Look for a refrigeration unit that is energy-efficient. This not only helps to reduce operating costs but also has a positive impact on the environment.
8. Reliability and Maintenance: The refrigeration unit should be reliable and have a good track record of performance.
Logistics refrigerated trucks are outfitted with top-notch insulation materials. The body panels typically consist of a thick layer of polyurethane foam sandwiched between two metal sheets.
Equipped with advanced refrigeration units, these trucks offer pinpoint temperature control. Operators can set and maintain specific temperatures depending on the cargo requirements.
A well-designed air circulation system is integral to these trucks. It comprises strategically placed fans and ducts that work in tandem to distribute cold air evenly across the cargo area.
The chassis of logistics refrigerated trucks is heavy-duty, built to bear the weight of the insulated body and substantial cargo loads.
Inside, there are adjustable shelves and racks that can be customized to fit various sizes and shapes of packages. This flexibility optimizes cargo space utilization and keeps items organized during transit.
The refrigeration system is the heart of these trucks, comprising components like compressors, condensers, evaporators, and thermostats. The compressor pumps refrigerant to absorb heat from the cargo area, with the condenser releasing that heat outside.
